L1400 electric wheel loader
To reserve or purchase a machine, reach out to us here on our Contact Us page.
The NESHER L1400 electric wheel loader is ideal for medium or heavier tasks thanks to its larger size and heavier lift capacity. It is a powerful yet easy-to-handle machine with a maximum lift capacity of 1,400 pounds (635 kg). With a 7-ft turning radius, this machine is nimbler than a ballerina.
The L1400 includes a quick-hitch for changing attachments without leaving the cab, full swinging doors, complete running lights, a comfortable right-side joystick for hydraulic functions, an adjustable operator’s chair, and many more features.
The L1400 includes one electric motor on each axle to provide AWD, and a third electric motor to power the hydraulic functions.
An air-cooled portable and wall-mountable charger is included to easily recharge the batteries from any typical 120V wall outlet.
The L1400 loader includes one general-purpose material bucket, which is good for sand, dirt, mulch, gravel, and other loose materials. Other attachments such as pallet forks, augers, excavators, plows and other attachments are sold separately. See the attachments here.
To reserve or purchase a machine, reach out to us here on our Contact Us page.
The NESHER L1400 electric wheel loader is ideal for medium or heavier tasks thanks to its larger size and heavier lift capacity. It is a powerful yet easy-to-handle machine with a maximum lift capacity of 1,400 pounds (635 kg). With a 7-ft turning radius, this machine is nimbler than a ballerina.
The L1400 includes a quick-hitch for changing attachments without leaving the cab, full swinging doors, complete running lights, a comfortable right-side joystick for hydraulic functions, an adjustable operator’s chair, and many more features.
The L1400 includes one electric motor on each axle to provide AWD, and a third electric motor to power the hydraulic functions.
An air-cooled portable and wall-mountable charger is included to easily recharge the batteries from any typical 120V wall outlet.
The L1400 loader includes one general-purpose material bucket, which is good for sand, dirt, mulch, gravel, and other loose materials. Other attachments such as pallet forks, augers, excavators, plows and other attachments are sold separately. See the attachments here.
To reserve or purchase a machine, reach out to us here on our Contact Us page.
The NESHER L1400 electric wheel loader is ideal for medium or heavier tasks thanks to its larger size and heavier lift capacity. It is a powerful yet easy-to-handle machine with a maximum lift capacity of 1,400 pounds (635 kg). With a 7-ft turning radius, this machine is nimbler than a ballerina.
The L1400 includes a quick-hitch for changing attachments without leaving the cab, full swinging doors, complete running lights, a comfortable right-side joystick for hydraulic functions, an adjustable operator’s chair, and many more features.
The L1400 includes one electric motor on each axle to provide AWD, and a third electric motor to power the hydraulic functions.
An air-cooled portable and wall-mountable charger is included to easily recharge the batteries from any typical 120V wall outlet.
The L1400 loader includes one general-purpose material bucket, which is good for sand, dirt, mulch, gravel, and other loose materials. Other attachments such as pallet forks, augers, excavators, plows and other attachments are sold separately. See the attachments here.
Tech specs
Bucket capacity: 0.33 cubic yards (0.25 cubic meters)
Rated load: 1,400 pounds (635 kg)
Low gear speed: 6 mph (10 km/h)
High gear speed: 12 mph (20 km/h)
Battery voltage: 72V 200Ah
Battery capacity: 14.4kWh
Battery type: Maintenance-free AGM battery
Charge time from 110VAC wall outlet: 8 hours
Working time: 4-6 hours depending on work intensity
Drive motors: Total of 10 kW continuous-rated
Tires: 27x10.5-15
Brakes: Hydraulic drum brakes
Hydraulic system
Hydraulic system motor: 5 kW continuous-rated
Hydraulic pressure: 16 MPa
Hydraulic flow rate: 4.8 gal/min on low, 13.3 gal/min on high
Dimensions
Total weight: 4,520 lb (2,050 kg)
Max length (with bucket lowered): 12’6” (3.81 m)
Total width: 3’10” (1.16 m)
Bucket width: 3’10” (1.16 m)
Max bucket lift height: 10’11” (3.33 m)
Max bucket dump height: 7’1” (2.16 m)
Height at top of canopy: 7’5” (2.26 m)
Wheelbase: 4’6” (1.37 m)
Angle of articlation: 45º
Turning radius: 7’0” (2.13m)
